High Quality 0.4mm Rigid Black PVC Sheet for Vacuum Forming

Specifications

PVC material and Its properties

1.Density is about:1.5g/cm³

2.Its thickness is uniform,strong tensile, corrosion resistance, transparency.

3.It is flame retardant, moisture-proof, waterproof, insulation, good anti-fouling force.

4.PVC material is not environmental protection, but can pass the ROHS certification, SGS report, exported to Europe and the United States,Germany,Japan,Southeast Asia and the Middle East .

Black Rigid PVC Sheet for Vacuum Forming — Sheet, Roll and Cut-to-Size

Looking for a black rigid PVC sheet for vacuum forming that behaves the same on every roll? We extrude vacuum forming grade PVC sheet in matte black from

【0.07mm】film up to 【10 mm】rigid board, supplied as flat sheet, roll stock for inline formers, or cut to your platen size. Gauge is held across the full width, so

the heater profile you set on the first roll still works on the fifth.

What Buyers Form From Our Black Rigid PVC Sheet

Thermoforming trays

Blister packaging

Electronic component carrier trays

Machine guards and equipment covers

Automotive interior trim

Retail display and kiosk panels

Appliance parts

FAQ

What thickness PVC sheet should I use for vacuum forming?

It follows your draw depth and corner radii, not a fixed rule. Shallow trays commonly start around 【0.3–0.5 mm】; structural covers and guards usually need

【1.5–3 mm】. Send the draw ratio and we will calculate the starting gauge and tell you where the thin point lands.

Is rigid PVC good for vacuum forming?

Yes — it has a broad forming window, low shrink, and it is self-extinguishing. It is a poor choice only when you need optical clarity (use PETG) or repeated low

temperature impact (use ABS).

What is the vacuum forming temperature for rigid PVC sheet?

Black stock absorbs radiant heat faster than clear, so dwell time usually drops when you switch. We supply a recommended starting profile with the first shipment

and fine-tune with you after trial

Why do my vacuum formed corners thin out?

Usually draw ratio, sheet temperature distribution or plug assist — not the mold. Gauge variation across the sheet width makes it worse, which is why we monitor

thickness in production rather than only at the sample cut.

Do you supply flame retardant black PVC sheet with UL 94 V-0?

FR grades are available and 【test reports / certificates】are issued with the order. Send your customer's spec and we will confirm the grade before quoting.

Can the sheet be cut to size or supplied as roll?

Both. Flat sheet, cut-to-size panels, or slit roll wound to your machine's width, core and maximum diameter.
