Thickness Tolerance |
According to GB(higher than GB) |
Density |
1.35g/cm3 |
Place of Origin |
Jiangsu, China |
Thickness |
0.15-3mm |
Certificate |
ROHS/Reach/ISO9001 |
Size |
custom size |
Surface |
Glossy |
Color |
Clear or Customized Color |
MOQ |
500KG |
Width |
Within 1250mm |
Sample |
Available(free Sample) |
Tensile-Strength(lengthwise,crosswise),MPa |
≥52.0 |
Impact strength(cut)(four-way)KJ/M2 |
≥5.0 |
Drop impact strenght |
No fracture |
Vicat softening piont,°C |
≥75.0 |
Lengthwise |
-5.0--+5.0 |
Crosswise |
Deviation 0-3mm |
Feature of PET:
1.Excellent strength and clarity : 20% higher than the PVC film, low-temperature impact resistance is better than PVC film.It is not brittle around -40℃,customers often use PET film (10% thinner) to instead of PVC film
2.Good resistance to fold: PET film has no crack crease(white folding line), more suitable for the file surface decoration.
3.Recyclable, reusable and environmentally friendly
4.Manufactured in a clean and hygienic environment
5.Toxic free and odourless
Mechanical properties:
Tensile Strength: Usually within the range of 50 - 80 MPa to ensure that the sheet has sufficient tensile strength during the thermoforming process.
Impact Strength: Usually within the range of 5 - 15 kJ/m² to ensure that the sheet has adequate impact resistance.
Thermal properties:
Coefficient of Thermal Expansion: Usually within the range of 70 - 100 ppm/°C.
Heat Deflection Temperature: Usually within the range of 70 - 90°C to ensure that the sheet material has sufficient stability during processing and usage.
Processing performance:
Molding Temperature Range: Usually within the range of 240 - 280°C to ensure that the sheet can be successfully molded in the blow molding equipment.
Environmental Performance:
Chemical Resistance: Generally exhibits good resistance to acids, alkalis and solvents, suitable for use in various environments.
Weatherability: Usually has certain weather resistance, suitable for use in both indoor and outdoor environments.
Application:
PET has high transparency, and is more glossy than PVC film. It is more suitable for exquisite pack.
Food packaging(Can Keep food fresh for a longer duration):
Case and tray for confectionery, bakery, fruits, vegetable, fishery, meat productsDairy products, beverage cups, containers Lids for ingredients, lids for ice cream.
Stationery: Notebook Binding, Book Cover, Plastic Bags etc...
Blister packaging:Toys, accessories, batteries, commodities
Medical packaging:Containers for medical supplies, optical devices
General usage:Case for cosmetics, dolls, sports stuffs, writing materials, common box type cases, and other stuffs
Printing:Silk Printing, UV Offset Printing
Signage:Clothes Labels, Food Labels, Price tags etc...
All products have been verified by SGS 、REACH、RoHS and ISO to ensure quality.
We offer a wide range of PET materials in various widths and thicknesses, including full rolls of film sheets, PET flat sheets, single-sided or double-sided abdominal protection films, and they can be electrostatically treated. The actual parameters of the PET sheet used for thermoforming may vary depending on factors such as requirements, formulation, and processing techniques. If you need PET sheet rolls, it is recommended to contact Ocan to obtain the technical data sheet and accurate parameter information.
